Model : TXS03-03A

---

Specifications

Wide Field Plane-Scope Eyepiece: WF10X, WF16X

45mm DIN Achromatic Objective: 4X, 10X, 40X(S), 100X(S,Oil)

Total Magnification: 40X-1600X

Monocular Head, 30° Inclined, 360° Rotatable

Quardruple Nosepiece

Double Layers Mechanical Stage: 140X155mm, Moving Range X-Y: 70X50mm,Ø2-Ø30mm Iris Diaphragm And Ø32 Filter

ABBE Condenser: N.A. 1.25

Built-in Adjustable Brightness Halogen Lamp 6V/20W

Coaxial Coarse And Fine Focusing Adjustable Mechanism: 25mm, Precision: 0.002mm

Packings

Net Weight/Set: 5.4kg

Package: 1 Sets/Carton

38X34X50cm;

Gross Weight/Carton: 10.5kg
